1. Product Description:

SP type pump is a vertical centrifugal slurry pump. It is suitable for mining, coal mine, metallurgy, electric power and other industrial sectors. It is used to transport corrosive, coarse and high concentration pulp.

Model:

Two, structure elucidation:

The SP pump is a vertical centrifugal slurry pump. The inlet of the pump is vertical downward, and the outlet is vertical upward on the other side of the pump. Pump is mainly composed of lower filter, pump body, impeller, shaft, guard plate, bracket and other parts, the upper part of the pump bearing support; pump installed in the liquid, do not need any shaft seal, wear-resistant parts.

The transmission type of the pump is two kinds of BD and DC, that is, belt drive and direct drive. The depth of submerged liquid can be determined within the standard size range according to the actual needs of users.

Viewed from the direction of pump suction, rotate counterclockwise.

1. Shaft 2. Dust cover 3. Bearing 4. Bearing sleeve 5. Bearing body 6. Bearing 7. Bracket 8. Filter 9. Back shield 10. Impeller 11. Pump body 12. Lower filter 13. Outlet tube 14. Outlet flange 15. Bearing cover

Three. Range of performance:

Inlet diameter: 40-200mm

Traffic: 12.6-569m3/h

Lift: 5-34m

Rotate speed: 400-2200r/min

Power consumption: 1.1-160Kw
