I. product uses:

IS type pump is single stage single suction (axial suction) centrifugal pump, suitable for industrial and urban water supply, drainage, also can be used for agricultural irrigation and drainage. For the transportation of clear water or other liquids with physical and chemical properties similar to clean water, the temperature of the medium is not higher than 80%.

ISR type hot water pump for hot water delivery, its medium temperature is not higher than 120 degrees.

Range of performance of IS and ISR pumps (according to design point):

Rotate speed: 2900rmin 1450rmin

Inlet diameter: 50-200mm

Traffic: 6.3-400m3h

Lift: 5-125m

Two. Range of performance:

Inlet diameter: 50-200mm

Traffic: 6.3-400m3h

Lift: 5-125m

Rotate speed: 2900rmin 1450rmin

Power consumption: 0.55-110Kw

There are two forms of sealing: packing seal and mechanical seal.
